It is easy to attach and remove
It provides an excellent insulation performance : no electrical problems have occurred
Various product line-up are provided such as thermal conductivity, hardness, and thickness, etc
Excellent temperature stability from -40 to 200℃
Excellent flame retardancy of UL94-V0 level
Satisfies RoHS and REACH standards
| TYSS Series | Test Method | TYSS – 15 | TYSS – 30 | TYSS – 50 | TYSS – 90 | TYSS – 120 | TYSS – 150 |
|---|---|---|---|---|---|---|---|
| Appearance / Color | – | Green | Sky blue | Gray | Gray | Gray | Gray |
| Thickness [㎜] | ASTM D374 | 0.5 ~ 5.0 | 0.5 ~ 5.0 | 0.5 ~ 5.0 | 1.0 ~ 5.0 | 1.0 ~ 3.0 | 1.0 ~ 3.0 |
| Density [g/㎤] | ASTM D792 | 1.8 | 2.9 | 3.3 | 3.6 | 3.3 | 3.2 |
| Thermal Conductivity [W/m·k] | ASTM D5470 | 1.5 | 3.0 | 5.0 | 9.0 | 12.0 | 15.0 |
| Hardness [Shore 00] | ASTM D2240 | 55 | 55 | 55 | 60 | 60 | 60 |
| Breakdown Voltage [㎸/㎜] | ASTM D149 | > 10 | > 10 | > 10 | 5 | 0.2 | 7 |
| Volume Resistivity [Ω·㎝] | ASTM D257 | 1010 | 1010 | 1010 | 1010 | 1010 | 1010 |
| Flammability | UL94 | V-0 | V-0 | V-0 | V-0 | V-0 | V-0 |
